PolyAnno: Further Product Development 2

This is part of my series of posts about the PolyAnno project – more here

Separating PolyAnno from “The Polyglot Project”

I then intended to release the PolyAnno package separately from the project specifically for the University of Edinburgh. I felt that it was important to create reusable code specifically for the providing the combination of:

  • Leaflet IIIF + Leaflet Draw + OAM JSON-LD annotations
  • the voting and verification system
  • vectors + transcription + translation + metadata
  • capability for adding both Hypothesis commentary, and a userbase system on top

Firstly I needed to separate out the essential options for this package into the polyanno_setup function.


The function that takes one input, opts, a JSON object of the following format :

  "highlighting": Boolean,
  "minimising": Boolean,
  "voting": Boolean,
  "users": Object,
  "storage": Object


Highlighting Option

If false then this disables the highlighting functionality that enables any annotation targets present on the page to be ‘highlighted’ whenever a cursor hovers over an annotation.


The default, non-highlighted colours of objects can be defined by setting the variable polyanno_default_colours_array before running the setup. This is an array of three HTML colours in the format [editor_box, vector, span]. The default values are:

//[editor_box, vector, span]
polyanno_default_colours_array = ["buttonface","#03f","transparent"];

The highlighted colours that the objects change to are similarly defined by polyanno_highlight_colours_array with the defaults as follows:

//[editor_box, vector, span]
polyanno_highlight_colours_array = ["#EC0028","#EC0028","#EC0028"];

Storage Option

The storage field takes format:

  "base_url": String,
  "transcription": String,
  "translation": String,
  "vector": String,
  "annotation": String

If nothing is specified other than base_url then it simply assumes base_url + “/transcriptions”, “/translations”, “/vectors”, and “/annotations”. The storage assumes you are using polyanno_storage and the URLs mapping to the storage functions are assumed to be:


I never quite finished separating the two packages and so the users functionality was never implemented before the end of 2016, nor was Polyanno released as a separate package. However, within the Polyglot project, I began a more clear cut of the code.

Additionally I successfully separated out the PolyAnno Storage functionality into a separate package, as detailed in the next post.

Next: Polyanno Storage

This is part of my series of posts about the PolyAnno project – more here
